LS 1200 Hydraulic Stake Puller
$4,495.00
The LS 1200 Hydraulic Stake Puller is capable of pulling stakes from all brands, including those embedded in bars. It is designed to work on various surfaces such as blacktop, grass, and hardpan. The stake puller features a compact design, a safety shut-off mechanism, and flat-free tires for added convenience.
- Order Parts
- Specs
- Specs
- Owner's Manual
- Warranty
- Order Parts
- Repair
- Product Video
- Product Video
- Description
Dimensions
Length: 56″
Width: 24″
Height: 42″
Weight: LS2200 320 lbs.
Engine:
Honda 5.5hp GX160K1QX2
Oil Capacity: 0.63 US qt. (SAE 10w-30, API SF or SG Engine Oil)
Fuel Capacity: 0.95 US gallon (Unleaded gasoline with a pump octane rating of 86 or higher)
Spark Plug: NGK BPR6ES (Gap: 0.030)
Hydraulic System:
Hydraulic Pump: 2000 psi
Oil Capacity: 5 US qts. HD32 or Equivalent
Hydraulic Power: 6280 lbs.
Piston Diameter: 2″
Piston Stroke: 20″
Cycle Time: 17 seconds
Jaw Capacity: 1 ½” standard
Tires: 4.80-8Flat-Free
Warranty: 1 year*
Additional Features: LS2200 model: Self-propelled with variable speed control
Specifications subject to change without notice
*Provided machine is operated and maintained according to instructions
SPECS
| Master Chuck ID | 2.5” (63.5mm) |
| Driver Only Dimensions | 11″ W x 14″ D x 23.5″ H (280 x 356 x 597 mm) |
| Driver Only Weight | 42.2 lbs. (19.1 kg) |
| Engine | Honda GX35 4-stroke |
| BPM (beats per minute) | 1720 (approximate) |
| Fuel | Unleaded Gas, 86 octane or higher |
| Fuel Capacity | 0.67 qt. (0.63 ltr) |
| Engine Oil | SAE 10W-30 |
| Lubricant | RHINO® Pro Series Lubricant |
| Shipping Weight | 54.5 lbs. (25 kg) |
| Shipping Dimensions | 30.5″ W x 15″ D x 18.25″ H (775 x 381 x 464 mm) |
APPLICATIONS
| Types & Sizes of Posts to be Driven (outside dimensions) | Chuck/Adapter |
|---|---|
| Tent Stake, 3/4″ to 2-1/2″ | Tent Stake Chuck (Included) |
Learn more about our stake driver and its abilites!
Equipped with a powerful Honda 5.5 HP engine, the puller utilizes a 2″ hydraulic piston that delivers an impressive 6,200 lbs. of pulling force. The patented design sets it apart, ensuring efficient and reliable stake removal. Despite its robust capabilities, the stake puller remains relatively lightweight at approximately 320 lbs.
