Jack Jaw Tent Stake Puller Kit
$595.00
Introducing the JackJaw® 302 Tent Manual Stake Puller, equipped with an adjustable base for swift, easy, and secure removal of 3/4″ to 1 1/4″ tent stakes or rebar. Comes with AC009 Adapter.
- Order Parts
- Specs
- Specs
- Owner's Manual
- Warranty
- Order Parts
- Repair
- Product Video
- Product Video
- Description
Dimensions
Length: 56″
Width: 24″
Height: 42″
Weight: LS2200 320 lbs.
Engine:
Honda 5.5hp GX160K1QX2
Oil Capacity: 0.63 US qt. (SAE 10w-30, API SF or SG Engine Oil)
Fuel Capacity: 0.95 US gallon (Unleaded gasoline with a pump octane rating of 86 or higher)
Spark Plug: NGK BPR6ES (Gap: 0.030)
Hydraulic System:
Hydraulic Pump: 2000 psi
Oil Capacity: 5 US qts. HD32 or Equivalent
Hydraulic Power: 6280 lbs.
Piston Diameter: 2″
Piston Stroke: 20″
Cycle Time: 17 seconds
Jaw Capacity: 1 ½” standard
Tires: 4.80-8Flat-Free
Warranty: 1 year*
Additional Features: LS2200 model: Self-propelled with variable speed control
Specifications subject to change without notice
*Provided machine is operated and maintained according to instructions
SPECS
| Master Chuck ID | 2.5” (63.5mm) |
| Driver Only Dimensions | 11″ W x 14″ D x 23.5″ H (280 x 356 x 597 mm) |
| Driver Only Weight | 42.2 lbs. (19.1 kg) |
| Engine | Honda GX35 4-stroke |
| BPM (beats per minute) | 1720 (approximate) |
| Fuel | Unleaded Gas, 86 octane or higher |
| Fuel Capacity | 0.67 qt. (0.63 ltr) |
| Engine Oil | SAE 10W-30 |
| Lubricant | RHINO® Pro Series Lubricant |
| Shipping Weight | 54.5 lbs. (25 kg) |
| Shipping Dimensions | 30.5″ W x 15″ D x 18.25″ H (775 x 381 x 464 mm) |
APPLICATIONS
| Types & Sizes of Posts to be Driven (outside dimensions) | Chuck/Adapter |
|---|---|
| Tent Stake, 3/4″ to 2-1/2″ | Tent Stake Chuck (Included) |
Learn more about our stake driver and its abilites!
This innovative tent stake puller ensures a smooth extraction process, preventing any bending of stakes and avoiding damage to surfaces like asphalt by pulling stakes directly out of any terrain. If you’re searching for an efficient tool to assist in removing rebar or tent stakes, your solution is the JackJaw® 302 tent stake puller.
The JackJaw® 302 functions as a cost-effective and highly efficient tool, simplifying the removal of both rebar and tent stakes. It has earned the status of being our customers’ preferred tool, thanks to its reliability and effectiveness. With the optional stake bar adapter (AC0009), the JackJaw® 302 effortlessly pulls stakes from stake bars or flat base plates commonly used in clear span tents.
For more details and to acquire the JackJaw® 302 Tent Stake Puller, explore the information below. This exceptional tool is available through Green Monster Manufacturing – your trusted source for cutting-edge equipment!
